Introduction
M-7 Guide ring is made from polyester fabric and epoxy resin, It is also called epoxy guide and white guide ring.
M-7 Guide ring is for heavy duty hydraulics, used as piston and rod guide ring, it's function is to guide the piston and piston rod, absorb transverse forces, prevent metal-to-metal contact, and optimize the performance of the sealing system, plays a very important role in hydraulic and pneumatic sealing system.
Material Benefits
- Very low humidity absorption
- Improved Sliding behavior
- Good Chemical resistance
- High load bearing capacity
- Improved self-lubricating property
- High flexibility, easy installation
Technical properties
| Polymer Material | Color | Density g/cm3 | Compressive strength Mpa | Hardness Rockwell M | Water Absorption |
Sliding speed [m/s] |
Temperature |
|
Epoxy resin+polyester fabric |
White |
1.26 | 350 | 100 | ＜0.1% | 1.0 | -40℃ to 130℃ |
Typical Applications
M-7 Guide ring was developed to heavy duty cylinders, construction machinery cylinders, marine hydraulics, mining hydraulic support cylinders, presses and mobile hydraulics, etc.
